Microsoft Azure

Configuring the Veza integration for Microsoft Azure

Veza connects to Azure tenants using an App Registration granted read-only permissions for the Microsoft Graph API. You will need an app client ID, client secret, and the Azure tenant ID to enable the connection in Veza.

Adding an Azure tenant will parse all its services, including Azure AD as an Identity Provider (IdP), and Microsoft SharePoint Online as an additional data source.

See Notes & Supported Entities for more details and supported Microsoft services.

Required steps: Complete Steps 1, 2, 4, 5, and 8 to enable Azure AD/Entra ID discovery. Steps 3, 6, and 7 are optional enhancements for SharePoint, Azure subscriptions, and Key Vault.

Integrating with Microsoft Azure

Veza for Azure

To integrate with Microsoft Azure, you will need to create an App Registration with read-only permissions for the services to discover. You will enter the App Registration's credentials when adding the Veza integration:

1. Register a new application for Veza

1. From your Azure tenant profile, navigate to App Registrations > New Registration

2. Name the new application (for example Veza Integration)

3. Select Accounts in this organizational directory only (tenantname only - Single tenant), and click "Register" to save your changes.

For more information, see the full instructions from Microsoft.

2. Grant permissions for the new app

1. With the new app registration selected, choose Manage > API Permissions and click "Add a Permission"

2. Choose Microsoft Graph, click "Application Permissions" and grant the required permissions and optional permissions listed below.

3. Optional for Lifecycle Management: For Lifecycle Management support, additional permissions are required. See the Azure Lifecycle Management integration guide for the complete list of required permissions.

4. Enable "Grant Admin Consent" on the API permissions screen.

Check that Admin Consent is granted

The delegated User.Read permission should be granted automatically. If it isn't present, add the permission from Add a Permission > Microsoft Graph > Delegated Permissions.

Required permissions

The following Microsoft Graph application permissions are required. Extraction will fail without them.

• AuditLog.Read.All: Reads /reports/authenticationMethods/userRegistrationDetails. Used to collect last sign-in dates and authentication method details for users.

• CustomSecAttributeAssignment.Read.All: Reads the customSecurityAttributes property on /users/{id}. Used to collect custom security attribute values assigned to users.

• DeviceManagementManagedDevices.Read.All: Reads /deviceManagement/managedDevices. Used to collect Intune-managed devices.

• DeviceManagementRBAC.Read.All: Reads /deviceManagement/roleAssignments and /deviceManagement/roleDefinitions. Used to collect Intune RBAC role assignments and role definitions.

• Directory.Read.All: Reads /users, /groups, /directoryRoles, /roleDefinitions, /oauth2PermissionGrants, and other directory endpoints. Provides read access to core directory objects including users, groups, roles, service principals, and organization data. Also provides the access described in Permissions covered by Directory.Read.All below.

• IdentityRiskyUser.Read.All: Reads /identityProtection/riskyUsers. Used to collect user risk levels from Identity Protection.

• Reports.Read.All: Reads /reports/getSharePointActivityUserDetail. Used to collect SharePoint activity and usage reports.

• Sites.Read.All: Reads /sites, /sites/getAllSites, /sites/root, and /sites/{id}/drives. Used to collect SharePoint site properties, structure, and drive metadata.

Optional permissions

These permissions enable additional features. Extraction will succeed without them, but the corresponding entities will not be collected.

• InformationProtectionPolicy.Read.All: Reads /beta/security/informationProtection/sensitivityLabels. Used to collect sensitivity labels.

• Policy.Read.All: Reads /identity/conditionalAccess/policies. Used to collect Conditional Access policies for service principals.

• Policy.Read.AuthenticationMethod: Reads /policies/authenticationMethodsPolicy. Used to collect authentication method configuration.

• PrivilegedAccess.Read.AzureAD: Reads /privilegedAccess/aadRoles. Used to collect PIM eligible role assignments.

• RoleEligibilitySchedule.Read.Directory: Reads /roleManagement/directory/roleEligibilitySchedules. Used to collect PIM role eligibility schedules.

• SecurityEvents.Read.All: Reads /security/secureScores. Used to collect tenant secure scores.

• SharePointTenantSettings.Read.All: Reads /admin/sharepoint/settings. Used to collect SharePoint sharing capability settings.

• Sites.FullControl.All: Reads /sites/{id}/permissions. Used to collect SharePoint site permission assignments.

Permissions covered by Directory.Read.All

The required Directory.Read.All permission already provides read access to the following APIs. You do not need to grant these permissions separately. They are listed here as granular replacements for organizations that need to remove Directory.Read.All in favor of least-privilege alternatives.

• Application.Read.All: Reads /applications and /servicePrincipals. Used to collect app registrations and service principals.

• Device.Read.All: Reads /devices. Used to collect Entra ID device objects.

• Domain.Read.All: Reads /domains. Used to collect tenant domains.

• Group.Read.All: Reads /groups. Used to collect group properties and memberships.

• GroupMember.Read.All: Reads /groups/{id}/members and /groups/{id}/owners. Used to collect group membership and ownership details.

• Organization.Read.All: Reads /organization. Used to collect organization-level properties.

• RoleManagement.Read.All: Reads /roleManagement/directory/roleAssignments and /roleManagement/directory/roleDefinitions. Used to collect PIM role assignments and role definitions.

• User.Read.All: Reads /users and /users/{id}. Used to collect user profiles and properties.

• User-Mail.ReadWrite.All: Reads the otherMails property on /users/{id}. Directory.Read.All provides read access to this property. The write scope is not used.

• User-PasswordProfile.ReadWrite.All: Reads the passwordProfile property on /users/{id}. Directory.Read.All provides read access to this property. The write scope is not used.

• User.EnableDisableAccount.All: Reads the accountEnabled property on /users/{id}. Directory.Read.All provides read access to this property. The write scope is not used.

The required Sites.Read.All permission also provides access to:

• Files.Read.All: Reads /drives/{id}/items, /drives/{id}/root, and /sites/{id}/drives. Used to collect drive items and file metadata.

Veza recommends Directory.Read.All because it provides the broadest compatibility. Organizations with strict permission policies can coordinate with Veza support to replace it with the granular permissions listed above.

3. Enable SharePoint integration (optional)

Skip this step if you don't need SharePoint. Continue to Step 4 to complete the required setup.

Additional API permissions are required if you plan to connect to SharePoint Online. To grant read-only access for Veza, choose SharePoint on the app registration "Add a Permission" screen, and grant the application permissions:

Adding additional SharePoint permissions

• User.Read.All

• Sites.Read.All

The app registration will also need the Reports.Read.All Microsoft Graph permission from the previous step.

For a complete overview and visual guide, see the official Azure documentation on configuring client application access.

Enable audit log parsing for activity-based extraction

Audit log extraction for SharePoint is provided as an Early Access feature. Please contact your support team to enable this configuration option.

When audit log extraction is enabled for an Azure tenant, Veza will gather audit logs using the Office 365 Management Activity API, and only connect to SharePoint Online for a full update when changes occur.

Enabling activity-based scheduling should help reduce lag between extractions, reducing the total time required to ingest large SharePoint environments. Please see below for the requirements and optional steps to enable:

1. Auditing must be enabled in the Microsoft Purview compliance portal

   1. Go to https://purview.microsoft.com and sign in. Click Audit.

   2. If auditing isn't enabled, a banner will prompt to Start recording user and admin activity.

   3. Click the banner to enable auditing, and wait for the changes to propogate.

   4. Alternatively, use the Exchange Power Shell:

      1. Set-AdminAuditLogConfig -UnifiedAuditLogIngestionEnabled $true

2. The Enterprise App used by Veza must have ActivityFeed.Read permission on the Office 365 Management API:

   1. When adding permisions to Enable SharePoint integration (optional), add the additional permission for the app registration: API permissions → Office 365 Management APIs → Application permissions → ActivityFeed.Read

3. After you finish integrating the Azure tenant, enable audit log extraction under Veza Configuration → Cloud Providers. The audit log status column should update to show that extraction is enabled:

enabling audit log extraction

4. Generate a Client Secret

1. From Certificates & Secrets, click "New Client Secret" and select an expiration date. Click "Add" to generate a new client secret value and ID.

2. Copy the client secret Value, which you'll use to configure the integration within Veza.

Mark down the client secret

5. Get the Application and Directory unique identifier

1. Open the Overview screen for the new application. Copy the Application (client) ID.

2. Copy the value for Directory (tenant) ID. You will need both values when adding the provider to Veza.

Retrieving Azure IDs

6. Assign the Reader role for the Veza app

For each Azure subscription to discover, you will need to add the new Veza app as a Reader. If you don't have any subscriptions (as will be the case if only integrating with Azure AD as an identity provider), this step is optional.

Assigning the reader role

1. From the Azure Subscription, select Access control (IAM)

2. Click on "+ Add" -> "Add role assignment"

3. Select "Reader" as the role

4. Select User, Group, or Service Principal" under Assign Access To

5. Select or search for the Veza app, and assign it the "Reader" role

6. (Optional) Assign the "Reader and Data Access" role to discover storage accounts and keys.

7. Save your changes

(Optional) Assign the Cosmos DB Account Reader role

To discover Azure CosmosDB resources, assign the Cosmos DB Account Reader role to the Veza app:

1. Navigate to your CosmosDB account in Azure Portal

2. Select Access control (IAM)

3. Click "+ Add" -> "Add role assignment"

4. Select "Cosmos DB Account Reader" as the role

5. Choose "User, Group, or Service Principal" under Assign access to

6. Search for and select the Veza app

7. Save the role assignment

This role provides the minimum required permissions to discover CosmosDB accounts, SQL role definitions, SQL role assignments, and databases. See Azure CosmosDB Support for more details.

7. Add Key Vault Permissions (Optional)

To connect to Azure Key Vault, a Key Vault access policy must grant the Veza app List permissions on Keys, Secrets, and Certificates. To create this policy:

1. On the Key Vaults services page, choose the vault Veza will discover.

2. Select Access policies.

3. Click + Create.

4. Select List under Key Permissions, Secret permissions, and Certificate permissions.

5. Click Next.

6. Search and select the Veza app as the Authorized Application.

7. Click Next, Next, and Create to save the policy.

Key Vault permissions for the Veza enterprise app.

7.1 Enable Key Vault Audit Logging (Optional)

To enable audit logging for Azure Key Vault operations and track key/secret access patterns:

1. Configure Key Vault Diagnostic Settings:

   • In the Azure portal, navigate to your Key Vault

   • Select Diagnostic settings from the monitoring section

   • Click + Add diagnostic setting

   • Provide a name for the diagnostic setting

2. Select Log Categories:

   • Enable AuditEvent - Key Vault audit events including key and secret access

   • Select Send to Log Analytics workspace as the destination

   • Choose or create a Log Analytics workspace

3. Grant Log Analytics Permissions:

   • Assign the Log Analytics Reader role to your Veza app registration on the Log Analytics workspace

   • Navigate to the Log Analytics workspace → Access control (IAM) → Add role assignment

   • Role: Select Log Analytics Reader

   • Assign access to: User, group, or service principal

   • Members: Search for and select your Veza app registration

   • Click Review + assign

4. Configure the Veza Integration:

   • When adding the Azure tenant to Veza (step 8), include the Log Analytics Workspace ID

   • The workspace ID can be found in the Azure portal under your Log Analytics workspace properties

   • Only one workspace ID can be specified per integration

When audit logging is enabled, Veza will extract key and secret access events from the AzureDiagnostics table and track rotation activities and timestamps for Access Monitoring dashboards and queries. For more information about Key Vault audit logs, see Microsoft Learn: Key Vault audit logging.

Veza reads from the AzureDiagnostics table (legacy collection mode). When configuring Diagnostic Settings, select Azure diagnostics as the destination table — not Resource specific. If resource-specific mode is configured, logs are written to AZKVAuditLogs and Veza will not find them.

Supported Key Vault Operations:

• Secret operations: Get, Set, Update, Delete, Purge, Recover, Backup, Restore, GetDeleted, ListDeleted, NearExpiryEventGridNotification, ExpiredEventGridNotification, ResourceGet

• Key operations: Get, Set, Update, Delete, Purge, Recover, Backup, Restore, GetDeleted, ListDeleted, NearExpiryEventGridNotification, ExpiredEventGridNotification, ResourceGet

• Vault operations: Get (vault metadata)

Note: Key Vault audit logging uses existing Azure app registration credentials to authenticate to the Log Analytics API. No additional Microsoft Graph API permissions are required beyond the Log Analytics Reader role on the workspace.

8. Add the Azure tenant to Veza

After completing the steps above, you can add the credentials and enable discovery by navigating to Veza Integrations > Add Integration. Choose Azure as the Integration Type.

Field	Notes
Insight Point	Leave default unless using an Insight Point
Name	Friendly name for the account
Tenant ID	Azure tenant ID to discover
Application ID	App UUID
Client Secret Value	App client secret value
Auth Certificate	Optional certificate for connecting to SharePoint
Auth certificate password	Password for SharePoint certificate (optional)
Subscription ID Allow List	Comma-separated list of subscription IDs; if present, discovery will be limited to the listed subscriptions (optional)
Subscription ID Deny List	Comma-separated list of subscription IDs; if present, listed subscriptions will be excluded from discovery (optional)
Limit Azure services extracted	Choose individual services to discover (See below)
Domains	Comma-separated list of domains to discover, ignoring any others
Dynamics 365 CRM Environments	Optional list of Dynamics 365 CRM environments to discover, e.g. https://org50e57fbd.crm.dynamics.com.
Dynamics 365 ERP Environments	Optional list of Dynamics 365 ERP environments to discover, e.g. https://company.operations.dynamics.com.
Azure Gov Cloud	Azure Government Cloud region where the tenant is located (currently supported: "None," "US").
Extract PIM Eligibility	Optionally discover temporary role assumptions based on Privileged Identity Management scheduling rules.
Log Analytics Workspace ID	Optional. Single workspace ID for Key Vault audit log extraction.

Veza will gather metadata for all discovered Azure AD (Entra ID) domains for the tenant. Use the Domains list to only include the specified domains in the extraction.

Limit Services

Additional options when adding or editing an integration enable limits on the data sources and identities that are extracted. When configuring limited services, you can select specific Microsoft 365 services to enable, including:

• Exchange Online - Email permissions and distribution groups (see Exchange Online setup)

• SharePoint - Document and site permissions

• Teams - Team channels and collaboration access

• Intune - Device management

• And other Azure services (SQL Server, Azure VM, CosmosDB, etc.)

Option	Details
Gather disabled users	Whether to include disabled users
Gather guest users	Whether to parse identity metadata for Azure AD Guest users
Gather personal sites	Whether to include personal SharePoint sites
Gather Group Extra Information	Whether to collect additional group attributes (allow_external_senders, hide_from_address_lists, hide_from_outlook_clients). Requires separate API calls that significantly increase extraction time. Unchecking improves performance but loses these group attributes.
Gather Group Owner Details	Whether to identify and collect group ownership information. Requires additional API calls that can delay extraction. Unchecking improves performance but loses group ownership visibility.
Data source allow/deny lists	Indicate resources to ignore by name or *
Custom Properties	Indicate custom security attributes to gather

Azure Subscription Filtering

You can control which Azure subscriptions are discovered by configuring subscription allow and deny lists. This is particularly useful for focusing extraction on production or specific environment subscriptions, excluding test, development, or deprecated subscriptions, and improving extraction performance by reducing API calls.

To configure subscription filtering:

1. When adding or editing an Azure integration, navigate to the Advanced Settings section

2. Use the following fields:

   • Subscription ID Allow List: Comma-separated list of subscription IDs to include (if specified, only these subscriptions will be extracted)

   • Subscription ID Deny List: Comma-separated list of subscription IDs to exclude

Examples:

• To extract only production subscriptions: Add their IDs to the allow list

• To exclude dev/test subscriptions: Add their IDs to the deny list

• If both lists are provided, the allow list takes precedence

Subscription filtering applies to all Azure services including RBAC, Storage, SQL, PostgreSQL, CosmosDB, Key Vault, AKS, and others. The filtering occurs at the subscription discovery level, ensuring consistent behavior across all extractors.

Troubleshooting

If the initial connection fails with the status "Insufficient privileges to complete the operation," validate that the correct API Permissions are granted, and are granted with the type application and not delegated.

Connecting to SharePoint

To connect to SharePoint Online, Veza requires an X.509 certificate for app-only authentication. You can generate the certificate directly in Veza or provide a .PFX file generated externally. You will also need to grant User.Read.All and Sites.Read.All permissions to the Veza app. See the SharePoint setup instructions for the full configuration steps.

Custom Security Attributes

Veza can optionally gather and show custom security attributes on Azure AD objects. The custom properties to discover must be identified by name and type in the Azure tenant configuration.

An Azure AD Premium P1 or P2 license is required to use Custom Attributes for Azure AD. The Enterprise Application used by Veza must have the CustomSecAttributeAssignment.Read.All Microsoft Graph permission.

To enable custom property extraction:

1. Add or edit a new Azure cloud provider configuration.

2. On the provider configuration modal, click + Add Custom Property.

3. Provide the type and name of the custom property.

   1. For Azure AD, the name is the attribute name of the custom security attribute. The data type is a property of the custom security attribute (Boolean, Integer, or String).

   2. For example: (EngineeringCertification, Boolean), (MarketingLevel, String).

   3. If the custom properties are part of an Attribute Set, include the attribute set name as a prefix, for example <AttributeSetName>_<AttributeName>.

4. Save the configuration. The custom attributes will be collected the next time the data source is parsed.

Enable Privileged Identity Management (PIM)

Veza supports Azure Privileged Identity Management (PIM) for both roles and groups. For more information about PIM support, see the Azure AD documentation.

To enable PIM extraction:

1. Ensure the required permissions are granted to the Veza app:

   • RoleManagement.Read.All

   • PrivilegedAccess.Read.AzureAD

   • Group.Read.All

2. When configuring the Azure integration, set the "Extract PIM Eligibility" option to "Yes"

3. Save the configuration. PIM assignments will be collected during the next extraction

Enable Dynamics 365

The Microsoft Azure integration includes optional support for Microsoft Dynamics 365. This integration allows Veza to discover connections between Azure AD Users, Groups, and Service Principals, and the permissions they can assume within Dynamics 365 environments.

Veza supports both Dynamics 365 CRM and Dynamics 365 ERP environments:

• Dynamics 365 CRM - Customer relationship management environments (URLs such as https://orgXXXXXXX.crm.dynamics.com)

• Dynamics 365 ERP - Enterprise resource planning environments (URLs such as https://xxx.operations.dynamics.com)

For full setup instructions and supported entities, see the specific integration guides.

Enable Microsoft Intune

The Microsoft Azure integration includes optional support for Intune, including Managed Devices and Role Definitions. Veza discovers and shows connections between Azure AD Users and Groups, and the Devices and Roles to which they are assigned in Intune.

In order to extract Intune, Veza requires the following Application Permissions for the Microsoft Graph API:

• DeviceManagementManagedDevices.Read.All

• DeviceManagementRBAC.Read.All

Enable Exchange Online

The Microsoft Azure integration includes optional support for Exchange Online, providing visibility into email and collaboration permissions. This integration discovers mailbox permissions, distribution groups, folder-level access controls, and delegation rights.

Important: Many organizations using Microsoft 365 require both Azure AD and Exchange Online visibility for complete access governance.

To enable Exchange Online:

1. Add API Permission: Grant Office 365 Exchange Online > Exchange.ManageAsApp permission to your Azure app registration

2. Assign Role: Add the Exchange Administrator role to your Azure app

3. Enable Service: In your Azure integration settings, go to Limit Services and select Exchange Online

For detailed setup instructions, see the Exchange Online integration guide.

Enable Microsoft Teams

To discover Microsoft Teams resources, including teams, channels, and relationships to external organization users, Veza requires the additional Graph API permissions:

• Team.ReadBasic.All

• TeamMember.Read.All

• Channel.ReadBasic.All

• ChannelMember.Read.All

• User.Read.All

Enable Azure AI Foundry

The Microsoft Azure integration includes optional support for Azure AI Foundry, providing visibility into AI services, model deployments, agents, and their access patterns. This integration discovers AI infrastructure resources and maps permissions to show which identities can access, deploy, or manage AI models.

Azure AI Foundry uses a two-tier permission model. The Veza service principal needs both control plane (ARM) permissions and data plane permissions to discover all resources. For detailed information about Azure AI Foundry RBAC, see Role-based access control for Azure AI Foundry.

To enable Azure AI Foundry extraction:

1. Assign Control Plane Role: The standard Reader role assigned at the subscription level (from Step 6) provides the required control plane permissions:

   • Microsoft.CognitiveServices/accounts/read

   • Microsoft.CognitiveServices/accounts/projects/read

   • Microsoft.CognitiveServices/accounts/deployments/read

   • Microsoft.CognitiveServices/accounts/raiPolicies/read

   • Microsoft.BotService/botServices/read

2. Assign Data Plane Role: Assign the Azure AI User role to the Veza app at the AI Foundry account or subscription level. This is Microsoft's recommended least-privilege role for read access to AI Foundry resources. For instructions on assigning Azure roles, see Assign Azure roles using the Azure portal.

   This role provides the data plane permissions required to discover:

   • Microsoft.CognitiveServices/accounts/AIServices/agents/read - AI agents

   • Microsoft.CognitiveServices/accounts/AIServices/vector_stores/read - Vector stores

   • Microsoft.CognitiveServices/accounts/AIServices/connections/read - Connections

   • Microsoft.CognitiveServices/accounts/AIServices/indexes/read - Search indexes

3. Enable Service: When configuring the Azure integration, go to Limit Services and select Azure AI Foundry

See Azure AI Foundry for the complete list of supported entities and properties.
